The ADPL-2 CH+ND puts a quad wavelength diode laser and a true Q-switched Nd:YAG in one portable cabinet. The diode side handles the hair list. The Nd:YAG handles tattoos, pigment, carbon peels and fungal nail, which are the treatments that keep a clinic busy between hair appointments.
Six treatments
- Laser hair removal, quad wavelength diode, all Fitzpatrick types with the appropriate protocol
- Tattoo removal, 1064nm and 532nm, including the R20 protocol
- SPMU removal, brows, lips and eyeliner
- Pigmentation correction, freckling, sun damage and age spots
- Carbon peel facial, the Hollywood facial
- Fungal nail eradication
Confirm with your own insurer that the applications you intend to offer are covered before you commit.
The diode side
- Quad wavelength 755 + 808 + 940 + 1064nm, blended output
- 800W laser, 2500W machine, US Coherent laser bars Ø6, 100 per cent pure AuSn stack
- Bar lifespan 20 million shots
- Three CH smart handle tips: Body 15 x 30mm, Facial 15 x 15mm, Mini Ø8mm
- 1 to 90 J/cm², 1 to 10Hz, 10 to 200ms
- Sapphire contact cooling, C-MAX ice technology rated to minus 20 degrees
The Q-switched Nd:YAG side
- 532nm, 1064nm and 1320nm
- 500W, up to 1000mJ peak energy
- 20 to 30 nanosecond Q-switched pulse, 1 to 10Hz
- Spot size adjustable 1 to 10mm
- UK xenon flash lamp, three million shot lifespan
Machine
- Sapphire crystal, air, closed water circulation, semiconductor and TEC cooling
- 11.6 or 15.6 inch true colour LCD touchscreen
- 10 to 12 hours continuous standby working
- 100 to 110V or 230 to 260V, 50 to 60Hz
- 33kg net, 42kg gross. Shipping 63 x 57 x 52cm
- Class 4 laser, BS EN 60825-1
Regulatory standing
Manufacturer Beijing Stelle Laser Technology Co., Ltd, SRN CN-MF-000038245. Class IIa. Basic UDI-DI 697669578ADPL2V6. GMDN 58786. Notified body TÜV Rheinland LGA Products GmbH 0197, EC Certificate HD 2264988-1 under Directive 93/42/EEC, surveillance audit confirmed 25 January 2024 and continued validity confirmed 12 April 2024 under Regulation (EU) 2023/607. Registered with the MHRA 24 May 2024, application reference 2024052201363378. UK Responsible Person: MedPath Limited, 27 Old Gloucester Street, London WC1N 3AX. Skintastic is the UK importer and distributor. Registration with the MHRA is not accreditation, certification, approval or endorsement.
Training and warranty
Machine operator training at our Southampton academy, with the Ofqual regulated Level 4 Certificate in Laser and IPL Skin Rejuvenation (RQF), or the Level 5 Diploma in Laser Tattoo Removal (RQF) where Level 4 is already held. Accommodation can be included for those travelling. Eighteen month warranty on the machine, twelve months on the diode bars and the Nd:YAG flash lamp. UK engineer support, spares and consumables held here.
